IN-LINE CLEANING UNITS

The line straightens and cuts the steel wire when it exits the dry wire drawing process, and it is specially used to produce electrode welding sticks. Installed at exit side of the wire drawing machine, the unit consists of two stages: the first degreases the wire while the second straightens and cuts the wire at high speed.

Main Features:

• 4+4 motorized rolls with pneumatic closing;
• Two roll-straightening panels placed at 90°, each composed of 8+9 rolls;
• Rotary shear;
• Belt extractor;
• Welding stick discharge revolving unit;
• Welding stick container with layering system and pusher
